Aluminum Nitride Lapping Services, Aluminum Nitride Substrates & Wafers
Aluminum Nitride (AlN) is a high-performance ceramic known for its excellent thermal conductivity, electrical insulation, mechanical strength, and chemical stability, making it ideal for applications in microelectronics and high-power electronics, with Valley Design offering AlN substrates and wafers featuring thermal conductivities of 175 to 200 W/mK.
AIN is a compound of aluminum and nitrogen. It is a high-performance ceramic material. It is known for its superior thermal conductivity, electrical insulation, and mechanical strength. Its efficient thermal conductivity allows it to transfer heat quickly and effectively. AIN is an excellent electrical insulator, preventing electrical current from flowing through the material despite its high thermal conductivity. It is resistant to thermal shock and demonstrates good mechanical strength. Additionally, it is chemically stable in inert atmospheres and in the presence of some acids and bases.
Due to these unique properties, AIN is the preferred choice for microelectronics, high-power electronics, laser components, insulators, heat sinks and other applications.
Valley Design stocks AlN substrates and wafers with thermal conductivities of 175 W/mK and 200 W/mK to meet various specifications. Quantities and pricing are subject to change.
High Thermal Conductivity Aluminum Nitride AlN Substrates
170 W/mK – 200 W/mK
For answers to your complex technological challenges, partner with a company that has continually led the way in innovation. We pioneered the processes and methods that are now the benchmark in producing substrates and components for MEMS and a variety of other applications. Contact us online or call 978-425-3030. Together, let’s make something extraordinary!
STOCK ITEMS
| For New Stock Items below: |
- Surface Finishes:
AF = As Fired
LBS = Lapped Both Sides (25u” Ra)
PBS = Polished Both Sides (2u” Ra)
P1S = Polished 1 Side (2u” Ra) / 2nd Side Lapped
- Improved tolerances, surface finishes and alternate sizes are also available.
- Visa, Mastercard, American Express and Purchasing Cards accepted.
|
| Item # |
Geometry (“) |
Geometry (mm) |
Finish |
Thermal Conductivity |
| AlN-101 |
6″ sq. x .320″ thk |
152.4mm sq. x 8.128mm thk |
AF |
170 W/mK |
| AlN-102 |
6″ sq. x .080″ thk |
152.4mm sq. x 2.032mm thk |
AF |
170 W/mK |
| AlN-103 |
4.6″ sq. x .050″ thk |
116.84mm sq. x 1.27mm thk |
LBS |
170 W/mK |
| AlN-104 |
4.6″ sq. x .045″ thk |
116.84mm sq. x 1.143mm thk |
LBS |
170 W/mK |
| AlN-105 |
4.567″ sq. x .040″ thk |
116.0018mm sq. x 1.016mm thk |
LBS |
170 W/mK |
| AlN-106 |
4.567″ sq. x .025″ thk |
116.0018mm sq. x .635mm thk |
LBS |
170 W/mK |
| AlN-107 |
4.5 x 3.75″ x .025″ ± .003″ thk |
114.3mm x .635mm ± .0762mm thk |
AF |
170 W/mK |
| AlN-108 |
4.5″ x 3.75″ x .031″ thk |
114.3mm x 95.25mm x .7874mm thk |
LBS |
170 W/mK |
| AlN-109 |
4.5″ sq. x .080″ thk |
114.3mm sq. x 2.032mm thk |
AF |
170 W/mK |
| AlN-110 |
4.5″ sq. x .080″ thk |
114.3mm sq. x 2.032mm thk |
LBS |
170 W/mK |
| AlN-111 |
4.5″ sq. x .060″ thk |
114.3mm sq. x 1.524mm thk |
LBS |
170 W/mK |
| AlN-112 |
4.5″ sq. x .040″ ± .001″ thk |
114.3mm sq. x 1.016mm ± .0254mm thk |
LBS |
170 W/mK |
| AlN-113 |
4.5″ sq. x .031″ thk |
114.3mm sq. x .7874mm thk |
AF |
170 W/mK |
| AlN-114 |
4.5″ sq. x .031″ thk |
114.3mm sq. x .7874mm thk |
PBS |
170 W/mK |
| AlN-115 |
4.49″ sq. x .080″ ± .0005″ thk |
114.046mm sq. x 2.032mm ± .0127mm thk |
LBS |
170 W/mK |
| AlN-116 |
4.48″ sq. x .039″ thk |
113.792mm sq. x .9906mm thk |
P1S |
170 W/mK |
| AlN-117 |
4.25″ x 2.9″ x .250″ thk |
107.95mm x 73.66mm x 6.35mm thk |
AF |
170 W/mK |
| AlN-118 |
4″ dia. x .060″ thk |
101.6mm dia. x 1.524mm thk |
LBS |
170 W/mK |
| AlN-119 |
4″ dia. x .040″ thk |
101.6mm dia. x 1.016mm thk |
P1S |
170 W/mK |
| AlN-120 |
4″ dia. x .025″ thk |
101.6mm dia. x .635mm thk |
PBS |
170 W/mK |
| AlN-121 |
4″ sq. x .103″ ± .001″ thk |
101.6mm sq. x 2.6162mm ± .0254mm thk |
LBS |
170 W/mK |
| AlN-122 |
4″ sq. x .100″ thk |
101.6mm sq. x 2.54mm thk |
AF |
170 W/mK |
| AlN-123 |
4″ sq. x .078″ thk |
101.6mm sq. x 1.9812mm thk |
P1S |
170 W/mK |
| AlN-124 |
4″ sq. x .050″ thk |
101.6mm sq. x 1.27mm thk |
LBS |
170 W/mK |
| AlN-125 |
4″ sq. x .026″ thk |
101.6mm sq. x .6604mm thk |
LBS |
170 W/mK |
| AlN-126 |
4″ sq. x .025″ thk |
101.6mm sq. x .635mm thk |
P1S |
200 W/mK |
| AlN-127 |
4″ sq. x .021″ thk |
101.6mm sq. x .5334mm thk |
LBS |
170 W/mK |
| AlN-128 |
4″ sq. x .015″ thk |
101.6mm sq. x .381mm thk |
P1S |
170 W/mK |
| AlN-129 |
3.543″ x 2.165″ x .157″ thk |
89.9922mm x 54.991mm x 3.9878mm thk |
AF |
170 W/mK |
| AlN-130 |
3.54″ dia. x .200″ thk |
89.916mm dia. x 5.08mm thk |
AF |
170 W/mK |
| AlN-131 |
3″ dia. x .015″ thk |
76.2mm dia. x .381mm thk |
P1S |
200 W/mK |
| AlN-132 |
3″ sq. x .080″ thk |
76.2mm sq. x 2.032mm thk |
AF |
170 W/mK |
| AlN-133 |
3″ sq. x .061″ thk |
76.2mm sq. x 1.5494mm thk |
LBS |
170 W/mK |
| AlN-134 |
3″ sq. x .03175″ thk |
76.2mm sq. x .80645mm thk |
LBS |
170 W/mK |
| AlN-135 |
3″ sq. x .0242″ thk |
76.2mm sq. x .61468mm thk |
PBS |
170 W/mK |
| AlN-136 |
3″ sq. x .014″ thk |
76.2mm sq. x .3556mm thk |
PBS |
170 W/mK |
| AlN-137 |
2.850″ x 2.25″ x .044″ thk |
72.39mm x 57.15mm x 1.1176mm thk |
LBS |
200 W/mK |
| AlN-138 |
2.165″ x .512″ x .040″ ± .001″ thk |
54.991mm x 13.0084mm x 1.016mm ± .0254mm thk |
LBS |
170 W/mK |
| AlN-139 |
2″ dia. x .040″ thk |
50.8mm dia. x 1.016mm thk |
P1S |
170 W/mK |
| AlN-140 |
2″ dia. x .0105″ thk |
50.8mm dia. x .2667mm thk |
P1S |
170 W/mK |
| AlN-141 |
2″ sq. x .136″ thk |
50.8mm sq. x 3.4544mm thk |
AF |
170 W/mK |
| AlN-142 |
2″ sq. x .100″ thk |
50.8mm sq. x 2.54mm thk |
AF |
170 W/mK |
| AlN-143 |
2″ sq. x .100″ thk |
50.8mm sq. x 2.54mm thk |
LBS |
170 W/mK |
| AlN-144 |
2″ sq. x .080″ thk |
50.8mm sq. x 2.032mm thk |
LBS |
170 W/mK |
| AlN-145 |
2″ sq. x .060″ thk |
50.8mm sq. x 1.524mm thk |
AF |
170 W/mK |
| AlN-146 |
2″ sq. x .048″ thk |
50.8mm sq. x 1.2192mm thk |
LBS |
170 W/mK |
| AlN-147 |
2″ sq. x .040″ thk |
50.8mm sq. x 1.016mm thk |
PBS |
200 W/mK |
| AlN-148 |
2″ sq. x .040″ thk |
50.8mm sq. x 1.016mm thk |
LBS |
170 W/mK |
| AlN-149 |
2″ sq. x .039″ thk |
50.8mm sq. x .9906mm thk |
AF |
170 W/mK |
| AlN-150 |
2″ sq. x .030″ thk |
50.8mm sq. x .762mm thk |
LBS |
170 W/mK |
| AlN-151 |
2″ sq. x .025″ thk |
50.8mm sq. x .635mm thk |
LBS |
200 W/mK |
| AlN-152 |
2″ sq. x .025″ thk |
50.8mm sq. x .635mm thk |
LBS |
170 W/mK |
| AlN-153 |
2″ sq. x .025″ thk |
50.8mm sq. x .635mm thk |
PBS |
170 W/mK |
| AlN-154 |
2″ sq. x .021″ thk |
50.8mm sq. x .5334mm thk |
LBS |
170 W/mK |
| AlN-155 |
2″ sq. x .020″ thk |
50.8mm sq. x .508mm thk |
PBS |
170 W/mK |
| AlN-156 |
1.964″ dia. x .059″ thk |
49.8856mm dia. x 1.4986mm thk |
AF |
200 W/mK |
| AlN-157 |
1.9″ sq. x .09448 ± .00003″ thk |
48.26mm sq. x 2.3998mm thk |
LBS |
170 W/mK |
| AlN-158 |
1.9″ sq. x .094″ thk |
48.26mm sq. x 2.3876mm thk |
P1S |
170 W/mK |
| AlN-159 |
1.9″ sq. x .07874 ± .0009″ thk |
48.26mm sq. x 1.999996mm ± .02286mm thk |
LBS |
170 W/mK |
| AlN-160 |
1.9″ sq. x .063″ thk |
48.26mm sq. x 1.6002mm thk |
P1S |
170 W/mK |
| AlN-161 |
1.8″ x .91″ x .321″ thk |
45.72mm x 23.114mm x 8.1534mm thk |
LBS |
170 W/mK |
| AlN-162 |
1.4″ x .600″ x .250″ thk |
35.56mm x 15.24mm x 6.35mm thk |
LBS |
170 W/mK |
